70/1000 AMB Deep Groove Ball Bearing
Searching for the best price?
Complete the inquiry form, we'll provide the most suitable solution.
Request Quote| Part Number | 70/1000 AMB |
| Category | Single Row General |
| Brand | JMP® |
| Interchangeable With | SKF |
| Bore Diameter | 1000.0000 mm |
| Outer Diameter | 1420.0000 mm |
| Width | 185.0000 mm |
| Bore Tolerance | -0.06mm to 0 |
| Outer Tolerance | -0.09mm to 0 |
| Width Tolerance | -0.05mm to 0 |
| Chamfer Dimension | 5.00 mm |
| Dynamic Radial Load | 1,631 lbf |
| Static Radial Load | 5,405 lbf |
| Construction | Single Row |
| Seal Type | Open |
| Contact Angle | 40.00 |
| Bearing Type | Ball |
| Load Direction | Angular Contact |
| System of Measurement | Metric |
| Ring Material | Chrome Steel |
| Ball / Roller Material | Chrome Steel |
| Cage Material | Brass |
| Reference Speed | 380 rpm |
| Limiting Speed (Grease) | — |
| Limiting Speed (Oil) | — |
| Tolerance Class | P6 (ABEC-3) |
| Bore Tolerance | -0.06mm to 0 |
| Outer Ring Tolerance | -0.09mm to 0 |
| Width Tolerance | -0.05mm to 0 |
| Temperature Range | -30° to 110 °C |
| RoHS | Compliant |
| REACH | Compliant |
| Weight | 890.0000 g |
| Lubrication | Lubricated |
| Brand | Equivalent |
|---|---|
| SKF | 70/1000 AMB |
The 70/1000 AMB is a high-quality Deep Groove Ball Bearing with bore diameter of 1000.0000 mm, outer diameter of 1420.0000 mm, and width of 185.0000 mm.
With a dynamic radial load rating of 1,631 lbf and static load rating of 5,405 lbf, the 70/1000 AMB is engineered to handle demanding operating conditions.
- Reliable load capacity for general industrial applications
- Optimized operating speed for stable performance
- Open design for easy relubrication and low friction operation
- Precision manufacturing to ISO standards ensures consistent quality
- Fully interchangeable with major international brands (SKF, NSK, FAG, NTN)
The 70/1000 AMB is available in Open (no seal), ZZ (metal shield), and 2RS (rubber seal) configurations. Open bearings offer higher speed ratings and lower friction, while sealed versions provide better contamination protection and reduced maintenance requirements.
JMP Bearings manufactures the 70/1000 AMB in various tolerance classes including ABEC-1 (standard), ABEC-3, ABEC-5 (precision), and ABEC-7 (high precision). Please contact us for specific tolerance class availability and pricing.
The 70/1000 AMB typically uses lithium-based grease (e.g., ISO VG 68) for general applications. For high-temperature or high-speed applications, synthetic greases such as polyurea-based lubricants are recommended. Contact our engineering team for application-specific lubrication guidance.
JMP Bearings offers flexible ordering - sample quantities are available from 1 piece. For bulk orders, we provide tiered pricing starting at 100, 500, and 1000+ pieces. Contact us for a custom quote tailored to your volume.
For standard 70/1000 AMB applications, shaft tolerance is typically k5 or j6, and housing tolerance is typically H7 or J6. Exact tolerance selections depend on load conditions, speed, and operating temperature. Refer to ISO 286 or consult our engineering support for detailed recommendations.
