SC-100-6 Thrust Ball Bearing
Searching for the best price?
Complete the inquiry form, we'll provide the most suitable solution.
Request Quote| Part Number | SC-100-6 |
| Category | Enclosed Style SC-100 Thrust Ball Bearing |
| Brand | JMP® |
| Interchangeable With | INA, NTN, HRB |
| Outer Diameter | 50.8000 in |
| Width | 17.4752 in |
| Outer Tolerance | 0'' to -0.005'' |
| Chamfer Dimension | — |
| Static Thrust Load | 13088.0 |
| Bearing Type | Ball |
| Load Direction | Thrust |
| System of Measurement | Inch |
| Ball / Roller Material | Chrome Steel |
| Ball Diameter | 0.313 |
| Ball Quantity | 15 |
| Temperature Range | -30° to 110°C |
| Max Temperature | 110 |
| Limiting Speed (Grease) | — |
| Limiting Speed (Oil) | — |
| Outer Ring Tolerance | 0'' to -0.005'' |
| RoHS | Compliant |
| REACH | Compliant |
| Weight | 0.6000 g |
Drawing not available — Request specs
| Brand | Equivalent |
|---|---|
| INA | SC-100-6 |
| NTN | SC-100-6 |
| HRB | SC-100-6 |
The SC-100-6 is a high-quality Thrust Ball Bearing with bore diameter of mm, outer diameter of 50.8000 mm, and width of 17.4752 mm.
With a dynamic radial load rating of 0 lbf and static load rating of 13,088 lbf, the SC-100-6 is engineered to handle demanding operating conditions.
- Reliable load capacity for general industrial applications
- Optimized operating speed for stable performance
- Open design for easy relubrication and low friction operation
- Precision manufacturing to ISO standards ensures consistent quality
- Fully interchangeable with major international brands (SKF, NSK, FAG, NTN)
The SC-100-6 is available in Open (no seal), ZZ (metal shield), and 2RS (rubber seal) configurations. Open bearings offer higher speed ratings and lower friction, while sealed versions provide better contamination protection and reduced maintenance requirements.
JMP Bearings manufactures the SC-100-6 in various tolerance classes including ABEC-1 (standard), ABEC-3, ABEC-5 (precision), and ABEC-7 (high precision). Please contact us for specific tolerance class availability and pricing.
The SC-100-6 typically uses lithium-based grease (e.g., ISO VG 68) for general applications. For high-temperature or high-speed applications, synthetic greases such as polyurea-based lubricants are recommended. Contact our engineering team for application-specific lubrication guidance.
JMP Bearings offers flexible ordering - sample quantities are available from 1 piece. For bulk orders, we provide tiered pricing starting at 100, 500, and 1000+ pieces. Contact us for a custom quote tailored to your volume.
For standard SC-100-6 applications, shaft tolerance is typically k5 or j6, and housing tolerance is typically H7 or J6. Exact tolerance selections depend on load conditions, speed, and operating temperature. Refer to ISO 286 or consult our engineering support for detailed recommendations.
